Polyester mesh Laid Scrims for Auto Industry Adhesive Tape
Polyester Laid Scrims Brief Introduction
This product is a Polyester Laid Scrim, a cost-effective, high-performance reinforcement fabric engineered specifically as the carrier / hidden tensile skeleton for automotive-industry adhesive tapes — including foam tape, rubber & plastic tape, and double-sided scrim tape used in interior trim mounting, exterior emblem attachment, weatherstrip bonding, NVH damping pads, wire-harness fixing, and light-seal/gasket positioning across passenger car, CV, and EV platforms. It is manufactured by chemically bonding continuous polyester filament yarns into an open mesh construction (square or tri-directional), with binder options (PVOH, PVC, Acrylic, or customized) to match different PSA coating, laminating, and die-cutting processes on automotive tape converting lines. Compared with glass-fiber scrims, the polyester version offers softer hand-feel, heat sealability, and better compatibility with acrylic / rubber-based PSAs — critical when the tape must survive under-hood heat cycles, NVH cabin environments, and automated die-cutting / robotic placement on vehicle lines. The scrim is laminated between adhesive layers or embedded into the tape carrier to become the "anti-stretch grid" that prevents elongation, tearing, and edge-lift during application and long-term service.
Polyester Laid Scrims Characteristics
Automotive-Tape Adapted Polyester Property Set: Per the page's "scrim" profile and the polyester variant's characteristics — tensile strength, tear resistance, heat sealable, anti-microbial properties, water resistance, self-adhesive compatibility, eco-friendly, decomposable, and recyclable. This combination lets the scrim reinforce foam-tape and double-sided tape carriers without compromising die-cut cleanliness, conformability to curved trim/body flanges, or long-term aging in vehicle environments (-40 °C to >100 °C under-hood, cabin NVH vibration cycles).。
High Strength & Light Weight: Page data sheet: CF12.5×12.5PH (12.5×12.5mm, 6.2–6.6 g/m²), CF10×10PH (10×10mm, 8–9 g/m²), CF6.25×6.25PH (6.25×6.25mm, 12–13.2 g/m²), CF5×5PH (5×5mm, 15.2 g/m²); regular supply mesh noted on page: 12.5×12.5mm, 10×10mm, 6.25×6.25mm, 5×5mm, 12.5×6.25mm etc.; regular supply grams: 6.5g, 8g, 13g, 15.5g etc. High strength-to-weight ratio lets the tape carrier gain tear resistance and dimensional stability without bulking up the roll or hurting flexibility around curved trim and body flanges.
Polyester Laid Scrims Data Sheet
|
Item No. |
CF12.5*12.5PH |
CF10*10PH |
CF6.25*6.25PH |
CF5*5PH |
|
Mesh Size |
12.5 x 12.5mm |
10 x 10mm |
6.25 x 6.25mm |
5 x 5mm |
|
Weight (g/m2) |
6.2-6.6g/m2 |
8-9g/m2 |
12-13.2g/m2 |
15.2-15.2g/m2 |
The regular supply of non-woven reinforcement and laminated scrim is 12.5x12.5mm,10x10mm,6.25x6.25mm, 5x5mm,12.5x6.25mm etc. The regular supply grams are 6.5g, 8g, 13g, 15.5g, etc.With high strength and light weight, it can be fully bonded with almost any material and each roll length can be 10,000 meters.
Polyester Laid Scrims Application
a) Aluminum Foil Composite
Nove-woven laid scrim is widely applied in aluminium foil industry. It can help manufacture to develop the production efficiency as the roll length can reach 10000m. It also makes the finished product with better apperance.
b) PVC Flooring
PVC Flooring is mainly made of PVC,also other necessary chemical material during manufacture. It is produced by calendering,extrusion progress or other manufacture progress, it is devided into PVC Sheet Floor and PVC Roller Floor. Now all major domestic and foreign manufactures are applying it as the reinforcement layer to avoiding the joint or bulge between pieces, which is caused by the heat expansion and contraction of materials.
c) None-woven category products reinforced
None-woven laid scrim is widely used as reinforced materail on kinds none-woven fabric, such as fiberglass tissue, polyester mat, wipes, also some top ends, such as medical paper. It can makes none-woven products with higher tensile strength,while just add very little unit weight.
d) PVC Tarpaulin
Laid scrim can be used as basic materials to produce truck cover,light awning, banner, sail cloth etc.
