SCRIM REINFORCED NONWOVEN CM3*10PH for Composite Flooring and TPO Applications，34 TEX Glass, SBR Adhesive
SCRIM REINFORCED NONWOVEN
SCRIM REINFORCED NONWOVEN Characteristics
Dual-Layer Composite Structure: The non-woven fabric provides bulk and a uniform surface, while the integrated glass fiber scrim delivers high tensile strength and dimensional stability in all directions.
High-Strength Reinforcement: The use of 34 TEX glass fibers in the scrim ensures exceptional load-bearing capacity and resistance to deformation.
Durable SBR Bonding: The SBR adhesive creates a strong, flexible, and moisture-resistant bond between the scrim and the non-woven, preventing delamination and ensuring long-term integrity.
Optimized for Polymer Matrices: The composite is engineered for excellent compatibility and adhesion with PVC (in flooring) and TPO polymers during the manufacturing of final products.
SCRIM REINFORCED Data Sheet
|
Item No. |
CF12.5*12.5PH |
CF10*10PH |
CF6.25*6.25PH |
CF5*5PH |
|
Mesh Size |
12.5 x 12.5mm |
10 x 10mm |
6.25 x 6.25mm |
5 x 5mm |
|
Weight (g/m2) |
6.2-6.6g/m2 |
8-9g/m2 |
12-13.2g/m2 |
15.2-15.2g/m2 |
The regular supply of non-woven reinforcement and laminated scrim is 12.5x12.5mm,10x10mm,6.25x6.25mm, 5x5mm,12.5x6.25mm etc. The regular supply grams are 6.5g, 8g, 13g, 15.5g, etc.With high strength and light weight, it can be fully bonded with almost any material and each roll length can be 10,000 meters.
SCRIM REINFORCED Application
Primary Use: Reinforcement for Composite Flooring & TPO Membrane Substrates
The core application of this scrim-reinforced nonwoven CM3 * 10PH is as the dual-layer reinforcement mat laminated into or behind the wear/print layer of composite flooring (PVC sheet/roller flooring) and TPO roofing membranes. It is integrated into the product stack to:
Stabilize PVC Flooring Against Thermal Expansion
In PVC composite flooring, the mat’s low-elongation glass scrim restrains differential movement between floor pieces caused by heat expansion/contraction, avoiding joint separation or surface bulging that compromises appearance and function. The SBR bond keeps the non-woven and scrim united through calender/extrusion.
Reinforce TPO Membranes for Roofing Loads
In TPO roofing, the mat adds multi-directional tensile and tear resistance under wind uplift, foot traffic, and thermal cycling, while the non-woven face improves polymer adhesion and provides a uniform backing that resists wrinkling during membrane laying.
Bridge Polymer–Substrate Interface
Because the composite is optimized for PVC and TPO matrices, it bridges the interface between the polymer top layer and any substrate or backing, reducing delamination risk in both flooring and roofing systems.
Secondary Applications
a) Aluminum Foil Composite
Nove-woven laid scrim is widely applied in aluminium foil industry. It can help manufacture to develop the production efficiency as the roll length can reach 10000m. It also makes the finished product with better apperance.
b) PVC Flooring
PVC Flooring is mainly made of PVC,also other necessary chemical material during manufacture. It is produced by calendering,extrusion progress or other manufacture progress, it is devided into PVC Sheet Floor and PVC Roller Floor. Now all major domestic and foreign manufactures are applying it as the reinforcement layer to avoiding the joint or bulge between pieces, which is caused by the heat expansion and contraction of materials.
c) None-woven category products reinforced
None-woven laid scrim is widely used as reinforced materail on kinds none-woven fabric, such as fiberglass tissue, polyester mat, wipes, also some top ends, such as medical paper. It can makes none-woven products with higher tensile strength,while just add very little unit weight.
d) PVC Tarpaulin
Laid scrim can be used as basic materials to produce truck cover,light awning, banner, sail cloth etc.
Due to lightweight, high strength, low shrinkage/elongation, corrosion preventive, laid scrims offers tremendous value compared to conventional material concepts. And it's easily to laminate with many kinds of materials, this makes it has an extensive fields of applications.
The SCRIM REINFORCED NON-WOVEN CM3*10PH is a high-quality non-woven scrim designed for reinforcing composite flooring and TPO membranes. Manufactured using 34 TEX fiberglass yarns and bonded with SBR adhesive, this scrim provides exceptional strength and stability, ensuring the durability and performance of the end product. This versatile material is ideal for various industrial applications, offering enhanced load-bearing capacity and dimensional stability.
