Polyester Laid Scrim Lightweight Tape Choice 2.5×6
Polyester Laid Scrims Brief Introduction
This product is a Polyester Laid Scrim in an ultra-lightweight, fine-mesh specification range (2.5×5 mm up to 8×12.5 mm), engineered specifically as the carrier / hidden tensile skeleton for light-duty adhesive tapes — including double-sided tape, foam tape, and thin PSA converts where low GSM and fine mesh openness are critical for coating bite and die-cut cleanliness. It is manufactured by chemically bonding continuous polyester filament yarns into a flat-laid open mesh (square or tri-directional optional), with binder options (PVOH, PVC, Acrylic, or customized) to match PSA coating, laminating, and slitting lines. Compared with heavier scrims, this lightweight tape series trades bulk for flexibility and conformability — the finer mesh (2.5×5 / 2.5×10 / 4×6 mm) lets thin-film adhesives and coatings bite through more evenly, while the scrim still arrests tear initiation and controls elongation. Configurable: roll width 200–2,500 mm, roll length up to 10,000 m, yarn types (Polyester led, also Glass, Carbon, Kevlar, Nomex, etc.), patterns 0.8–3 yarns/cm.
Polyester Laid Scrims Characteristics
Lightweight-Tape Adapted Polyester Properties: The scrim delivers tensile strength, dimensional stability, tear resistance, alkali resistance, fire resistance, anti-microbial properties, water resistance, and heat sealability — a profile that fits thin PSA carriers, double-sided foam tapes, and die-cut mounting tabs where the scrim must stay invisible in the stack while still controlling stretch and tear.
Long Rolls for High-Speed PSA Lines: Each roll length can be 10,000 meters, which helps manufacturers improve production efficiency and gives finished products better appearance. Fewer splices per shift on high-speed PSA coating and slitting lines, fewer weak spots in finished tape logs.
Polyester Laid Scrims Data Sheet
|
Item No. |
CP2.5*5PH |
CP2.5*10PH |
CP4*6PH |
CP8*12PH |
|
Mesh Size |
2.5 x 5mm |
2.5 x 10mm |
4 x 6mm |
8 x 12.5mm |
|
Weight (g/m2) |
5.5-6g/m2 |
4-5g/m2 |
7.8-10g/m2 |
2-2.5g/m2 |
The regular supply of non-woven reinforcement and laminated scrim is 2.5x5mm, 2.5x10mm, 3x10mm, 4x4mm, 4x6mm, 5x5mm, 6.25x12.5mm etc. The regular supply grams are 3g, 5g, 8g, 10g, etc.With high strength and light weight, it can be fully bonded with almost any material and each roll length can be 10,000 meters.
Polyester Laid Scrims Application
Primary Use: Reinforcement for Lightweight Adhesive Tapes
The core application of this lightweight polyester laid scrim (CP2.5×5 / CP2.5×10 / CP4×6 / CP8×12 series) is as the hidden tensile skeleton laminated between adhesive layers or embedded into the thin carrier of double-sided tape, foam tape, and die-cut PSA products. It is laminated into the tape stack to:
Control Elongation & Add Tear Resistance Without Bulking
The fine mesh (down to 2.5×5 mm) and ultra-low GSM (CP8×12 at 2–2.5 g/m²) let the scrim reinforce thin PSA carriers without adding thickness or stiffening the tape — critical for foam-tape and mounting-tab applications where the tape must flex around corners.
Enable Clean Die-Cutting & Coating Bite
The open, fine mesh allows the adhesive coating to key through evenly, and the scrim's flexibility ensures smooth unwinding on PSA coating and slitting lines, with minimal adhesive oozing or liner wrinkling — useful for high-spec die-cut tapes.
Maintain Dimensional Stability in Service
The scrim's low elongation prevents the tape from stretching when unrolled or loaded in shear, so die-cut shapes (logo tabs, mounting squares) stay in registered position after application.
Secondary Applications
a) Aluminum Foil Composite
Nove-woven laid scrim is widely applied in aluminium foil industry. It can help manufacture to develop the production efficiency as the roll length can reach 10000m. It also makes the finished product with better apperance.
b) PVC Flooring
PVC Flooring is mainly made of PVC,also other necessary chemical material during manufacture. It is produced by calendering,extrusion progress or other manufacture progress, it is devided into PVC Sheet Floor and PVC Roller Floor. Now all major domestic and foreign manufactures are applying it as the reinforcement layer to avoiding the joint or bulge between pieces, which is caused by the heat expansion and contraction of materials.
c) None-woven category products reinforced
None-woven laid scrim is widely used as reinforced materail on kinds none-woven fabric, such as fiberglass tissue, polyester mat, wipes, also some top ends, such as medical paper. It can makes none-woven products with higher tensile strength,while just add very little unit weight.
d) PVC Tarpaulin
Laid scrim can be used as basic materials to produce truck cover,light awning, banner, sail cloth etc.
