Non-woven Laid scrims for Building
Non-woven Laid scrims Introduction
This product is a Laid Scrim (glass, polyester, carbon, or hybrid) positioned as a multi-purpose reinforcement substrate for building-sector composites — including textile roofing shields, insulation facings, Alu–PE films, non-wovens, antistatic textiles, needle-punched non-wovens, pocket filters, tissues, and PVC flooring / carpet carriers. It is manufactured by chemically bonding continuous filament yarns (Glass, Polyester, Carbon, Cotton, Flax, Jute, Viscose, Kevlar, Nomex, etc.) into a flat-laid open mesh (square or tri-directional), then supplied as a standalone roll or pre-laminated carrier for integration into foil, non-woven, PVC, and technical textile stacks used onsite and offsite. Thanks to lightweight, high strength, low shrinkage / low elongation, and corrosion resistance, the scrim offers measurable value versus conventional reinforcement concepts, and bonds readily with many material systems common to building products.
Non-woven Laid scrims Characteristics
Building-Grade Property Menu: Depending on yarn choice, the scrim delivers high strength, dimensional stability, low shrinkage, low elongation, corrosion resistance, and (glass) alkali resistance & fire resistance, or (polyester) heat sealability & softer hand — letting specifying engineers pick the right scrim for roofing shields, insulation facings, filtration non-wovens, or flooring carriers.
Long Rolls for Building-Product Lines: Roll width 200–2,500 mm; each roll length can be 10,000 m (platform up to 50,000 m), helping manufacturers improve production efficiency and giving finished products better appearance. Fewer splices per shift on high-speed laminating, coating, needle-punch, and slitting lines feeding roofing, insulation, and flooring mills.
Non-woven Laid scrims Data Sheet
|
Item No. |
CF12.5*12.5PH |
CF10*10PH |
CF6.25*6.25PH |
CF5*5PH |
|
Mesh Size |
12.5 x 12.5mm |
10 x 10mm |
6.25 x 6.25mm |
5 x 5mm |
|
Weight (g/m2) |
6.2-6.6g/m2 |
8-9g/m2 |
12-13.2g/m2 |
15.2-15.2g/m2 |
The regular supply of non-woven reinforcement and laminated scrim is 12.5x12.5mm,10x10mm,6.25x6.25mm, 5x5mm,12.5x6.25mm etc. The regular supply grams are 6.5g, 8g, 13g, 15.5g, etc.With high strength and light weight, it can be fully bonded with almost any material and each roll length can be 10,000 meters.
Non-woven Laid scrims Application
Primary Use: Reinforcement Across Building-Sector Composites
The core positioning of this building-grade laid scrim is as the hidden tensile grid laminated into or between textile roofing shields, insulation facings, Alu–PE films, non-wovens, antistatic textiles, needle-punched non-wovens, pocket-filter media, tissues, and PVC flooring / carpet carriers. It is laminated into the host stack to:
Upgrade Mechanical Performance of Building Substrates
The scrim adds tensile & tear resistance at very low GSM, turning fragile or limp substrates (foil facings, thin non-wovens, needle-punched mats, PVC flooring layers) into composites that survive handling, converting, installation, and in-service loads (wind, thermal cycles, foot traffic).
Serve Multiple Building Sub-Segments from One Platform
Because the scrim is substrate-agnostic, the same roll can be specified into textile roofing shields, insulation & insulating material, Alu & PE films, non-wovens, antistatic textiles, needle-punched non-wovens, pocket filter, tissues, PVC flooring, carpet — an extensive field of applications that matches the building category's breadth.
Keep Lamination Lines Efficient
10,000 m roll length (up to 50,000 m platform) feeds high-speed laminators, coaters, needle-punch lines, and slitters with fewer splice stops — fewer weak spots in finished rolls, better batch appearance for building-product mills.
Secondary Applications
a) Aluminum Foil Composite
Nove-woven laid scrim is widely applied in aluminium foil industry. It can help manufacture to develop the production efficiency as the roll length can reach 10000m. It also makes the finished product with better apperance.
b) PVC Flooring
PVC Flooring is mainly made of PVC,also other necessary chemical material during manufacture. It is produced by calendering,extrusion progress or other manufacture progress, it is devided into PVC Sheet Floor and PVC Roller Floor. Now all major domestic and foreign manufactures are applying it as the reinforcement layer to avoiding the joint or bulge between pieces, which is caused by the heat expansion and contraction of materials.
c) None-woven category products reinforced
None-woven laid scrim is widely used as reinforced materail on kinds none-woven fabric, such as fiberglass tissue, polyester mat, wipes, also some top ends, such as medical paper. It can makes none-woven products with higher tensile strength,while just add very little unit weight.
d) PVC Tarpaulin
Laid scrim can be used as basic materials to produce truck cover,light awning, banner, sail cloth etc.
The First and Biggest manufacturer and supplier of laid scrims in china!
Due to lightweight, high strength, low shrinkage/elongation, corrosion preventive, laid scrims offers tremendous value compared to conventional material concepts. And it's easily to laminate with many kinds of materials, this makes it has an extensive fields of applications.
