Non-woven Laid scrims for laminated material
Non-woven Laid scrims Introduction
This product is a Laid Scrim (glass, polyester, or hybrid) presented as a universal reinforcement substrate for laminating with other materials — thanks to its light weight, high strength, low shrinkage / low elongation, and corrosion resistance, it offers significant value compared with conventional reinforcement concepts. The scrim is manufactured by chemically bonding continuous filament yarns (Glass, Polyester, Carbon, Kevlar, Nomex, Cotton, Flax, Jute, Viscose, etc.) into a flat-laid open mesh (square or tri-directional), then supplied as a standalone roll or pre-laminated carrier for integration into foil, non-woven, PVC, paper, and technical textile stacks.
Non-woven Laid scrims Characteristics
Lamination-Grade Property Profile: Depending on yarn choice, the scrim delivers high strength, dimensional stability, low shrinkage, low elongation, corrosion resistance, and (for glass) alkali resistance & fire resistance, or (for polyester) heat sealability, anti-microbial properties, water resistance, eco-friendliness — a flexible property menu that lets converters pick the right scrim for foil, PVC, non-woven, paper, or technical textile laminating lines.
Long Rolls & Process Compatibility: Roll width 200–2,500 mm; each roll length can be 10,000 meters, which helps manufacturers improve production efficiency and gives finished products better appearance. Fewer splices per shift on high-speed laminating, coating, and slitting lines, fewer weak spots in finished rolls.
Non-woven Laid scrims Data Sheet
|
Item No. |
CF12.5*12.5PH |
CF10*10PH |
CF6.25*6.25PH |
CF5*5PH |
|
Mesh Size |
12.5 x 12.5mm |
10 x 10mm |
6.25 x 6.25mm |
5 x 5mm |
|
Weight (g/m2) |
6.2-6.6g/m2 |
8-9g/m2 |
12-13.2g/m2 |
15.2-15.2g/m2 |
The regular supply of non-woven reinforcement and laminated scrim is 12.5x12.5mm,10x10mm,6.25x6.25mm, 5x5mm,12.5x6.25mm etc. The regular supply grams are 6.5g, 8g, 13g, 15.5g, etc.With high strength and light weight, it can be fully bonded with almost any material and each roll length can be 10,000 meters.
Non-woven Laid scrims Application
Primary Use: Universal Reinforcement Substrate for Laminating with Other Materials
The core positioning of this laid scrim range is as the "hidden tensile grid" that can be laminated with foil, non-woven, PVC, paper, tissue, mat, and technical textile stacks — wherever a converter needs to add multi-directional tensile, tear resistance, and dimensional stability to a host substrate without bulking it up. It is laminated into the host stack to:
Upgrade Mechanical Performance of Host Substrate
The scrim adds tensile & tear resistance at very low GSM, turning a fragile or limp substrate (foil-kraft, thin non-woven, tissue, PVC film) into a composite that survives handling, converting, and in-service loads.
Keep Lamination Lines Efficient
10,000 m roll length feeds high-speed laminators, coaters, and slitters with fewer splice stops — directly supporting the page's note that laid scrim "offers tremendous value compared to conventional material concepts" by lowering waste and improving roll appearance.
Serve as Platform Entry to Multiple End-Uses
Because the scrim itself is substrate-agnostic, the same roll can be specified into foil insulation, PVC tarpaulin, flooring, non-woven reinforcement, medical paper, and technical coated fabrics
Secondary Applications
a) Aluminum Foil Composite
Nove-woven laid scrim is widely applied in aluminium foil industry. It can help manufacture to develop the production efficiency as the roll length can reach 10000m. It also makes the finished product with better apperance.
b) PVC Flooring
PVC Flooring is mainly made of PVC,also other necessary chemical material during manufacture. It is produced by calendering,extrusion progress or other manufacture progress, it is devided into PVC Sheet Floor and PVC Roller Floor. Now all major domestic and foreign manufactures are applying it as the reinforcement layer to avoiding the joint or bulge between pieces, which is caused by the heat expansion and contraction of materials.
c) None-woven category products reinforced
None-woven laid scrim is widely used as reinforced materail on kinds none-woven fabric, such as fiberglass tissue, polyester mat, wipes, also some top ends, such as medical paper. It can makes none-woven products with higher tensile strength,while just add very little unit weight.
d) PVC Tarpaulin
Laid scrim can be used as basic materials to produce truck cover,light awning, banner, sail cloth etc.
The Professional manufacturer and supplier of laid scrims in China!
Laid scrims is the best material for laminating with many other kinds of materials, due to its light weight, high strength, low shrinkage/elongation, corrosion preventive, it offers tremendous value compared to conventional material concepts. This makes it has an extensive fields of applications.
