Fiberglass non-woven laid scrims 3×1 ENDS-10MM (3.3x10MM)
Fiberglass Laid Scrims Brief Introduction
This product is a rectangular-mesh Laid Scrim (available in Glass, Polyester, or hybrid), built on a 3×1 ENDS per 10 mm layout (3.3×10 mm grid) — a fine-by-coarse rectangular format where the denser 3 ENDS axis arrests fine tears while the open 1 END axis keeps the scrim breathable and resin/binder bite-friendly. It is made by chemically bonding continuous filament yarns (Glass, Polyester, Carbon, Cotton, Flax, Jute, Viscose, Kevlar, Nomex, etc.) into a flat-laid open mesh (square or tri-directional), then supplied as a standalone roll or laminated carrier for integration into foil, non-woven, PVC, and technical textile stacks. The chemically bonded, non-woven-yarn construction gives the scrim lightweight, high strength, low shrinkage/low elongation, and corrosion resistance.
Fiberglass Laid Scrims Characteristics
3.3×10 mm Rectangular Property Profile: Dimensional stability, tensile strength, alkali resistance, tear resistance, fire resistance, anti-microbial properties, water resistance — the 3×1 ENDS layout lets the converter tune warp/weft reinforcement ratio on rectangular grids (this 3.3×10 mm sits alongside the platform's 12.5×6.25 mm rectangular class), useful when the host substrate or process direction calls for differentiated MD/CD reinforcement.
High Strength & Light Weight: The platform's regular mesh range covers 12.5×12.5 / 10×10 / 6.25×6.25 / 5×5 / 12.5×6.25 mm etc., with regular supply grams 6.5g / 8g / 13g / 15.5g etc.; this item sits in the rectangular fine-by-coarse slot (3.3×10 mm, 3×1 ENDS). High strength-to-weight, fully bondable with almost any material; each roll length 10,000 m to support efficient production.
Fiberglass Laid Scrims Data Sheet
|
Item No. |
CF12.5*12.5PH |
CF10*10PH |
CF6.25*6.25PH |
CF5*5PH |
|
Mesh Size |
12.5 x 12.5mm |
10 x 10mm |
6.25 x 6.25mm |
5 x 5mm |
|
Weight (g/m2) |
6.2-6.6g/m2 |
8-9g/m2 |
12-13.2g/m2 |
15.2-15.2g/m2 |
The regular supply of non-woven reinforcement and laminated scrim is 12.5x12.5mm,10x10mm,6.25x6.25mm, 5x5mm,12.5x6.25mm etc. The regular supply grams are 6.5g, 8g, 13g, 15.5g, etc.With high strength and light weight, it can be fully bonded with almost any material and each roll length can be 10,000 meters.
Fiberglass Laid Scrims Application
Primary Use: Directionally Tuned Reinforcement for Rectangular-Grid Laminates
The core application of this 3×1 ENDS (3.3×10 mm) rectangular laid scrim is as the hidden tensile grid laminated into or between foil–kraft, non-woven mats, PVC carriers, and technical textile stacks where the converter wants differentiated MD/CD reinforcement rather than a symmetric square mesh. It is laminated into the host stack to upgrade mechanical performance at very low GSM, turning fragile or limp substrates into composites that survive handling, converting, and in-service loads. The 3×1 ENDS fine-by-coarse rectangular layout is particularly useful on laminating or winding lines where one axis sees dominant stress (e.g., machine-direction on laminators, or a bias direction on wraps).
Secondary Applications
a) Aluminum Foil Composite
Nove-woven laid scrim is widely applied in aluminium foil industry. It can help manufacture to develop the production efficiency as the roll length can reach 10000m. It also makes the finished product with better apperance.
b) PVC Flooring
PVC Flooring is mainly made of PVC,also other necessary chemical material during manufacture. It is produced by calendering,extrusion progress or other manufacture progress, it is devided into PVC Sheet Floor and PVC Roller Floor. Now all major domestic and foreign manufactures are applying it as the reinforcement layer to avoiding the joint or bulge between pieces, which is caused by the heat expansion and contraction of materials.
c) None-woven category products reinforced
None-woven laid scrim is widely used as reinforced materail on kinds none-woven fabric, such as fiberglass tissue, polyester mat, wipes, also some top ends, such as medical paper. It can makes none-woven products with higher tensile strength,while just add very little unit weight.
d) PVC Tarpaulin
Laid scrim can be used as basic materials to produce truck cover,light awning, banner, sail cloth etc.
