Fireproof None-woven Laid Scrim
Fireproof None-woven Laid Scrim Introduction
This product is a fireproof-grade Laid Scrim (glass, polyester, or hybrid), a cost-effective, open-mesh reinforcement fabric whose core differentiation is the fire resistance built into the scrim itself — either via E-glass filaments (inherently non-combustible) or via flame-retardant binder systems (PVOH, PVC, Acrylic, or customized) on polyester versions. It is manufactured by chemically bonding continuous filament yarns into a flat-laid open mesh (square or tri-directional), then supplied as a standalone roll or laminated carrier for integration into aluminium foil, PVC flooring, non-woven composites, and technical textile stacks where a fire-rated reinforcement layer is specified. Ruifiber makes these scrims to order for specific usages — designed to satisfy customer requests and be highly compatible with their process and product.
Fireproof None-woven Laid Scrim Characteristics
Fireproof-Grade Property Profile: Dimensional stability, tensile strength, alkali resistance, tear resistance, fire resistance, anti-microbial properties, water resistance — the glass version is inherently non-combustible; the polyester version can be paired with FR binders to meet specified flame-class requirements while keeping softer hand and heat-sealability. This combination lets the scrim reinforce foil, flooring, non-woven, and coated-fabric stacks in projects where a fire-rated substrate is part of the spec (building wrap, public-space flooring, transport interiors, industrial insulation).
High Strength & Light Weight: Available in a range of regular mesh sizes and grammages covering the platform's common specifications (12.5×12.5 / 10×10 / 6.25×6.25 / 5×5 / 12.5×6.25 mm etc.; regular supply grams 6.5g / 8g / 13g / 15.5g etc., mapping to CF12.5×12.5PH ~6.2–6.6 g/m², CF10×10PH 8–9, CF6.25×6.25PH 12–13.2, CF5×5PH 15.2). High strength-to-weight, fully bondable with almost any material; each roll length 10,000 m to support efficient production.
Fireproof None-woven Laid Scrim Data Sheet
|
Item No. |
CF12.5*12.5PH |
CF10*10PH |
CF6.25*6.25PH |
CF5*5PH |
|
Mesh Size |
12.5 x 12.5mm |
10 x 10mm |
6.25 x 6.25mm |
5 x 5mm |
|
Weight (g/m2) |
6.2-6.6g/m2 |
8-9g/m2 |
12-13.2g/m2 |
15.2-15.2g/m2 |
The regular supply of non-woven reinforcement and laminated scrim is 12.5x12.5mm,10x10mm,6.25x6.25mm, 5x5mm,12.5x6.25mm etc. The regular supply grams are 6.5g, 8g, 13g, 15.5g, etc.With high strength and light weight, it can be fully bonded with almost any material and each roll length can be 10,000 meters.
Fireproof None-woven Laid Scrim Application
Primary Use: Fire-Rated Reinforcement Substrate Where Flame Resistance Is Specified
The core positioning of this fireproof laid scrim is as the hidden tensile grid laminated into or between foil, non-woven, PVC, and technical textile stacks on projects where a fire-rated substrate is part of the specification — building wrap, public-space flooring, transport interiors, and industrial insulation facing. It is laminated into the host stack to upgrade mechanical performance at very low GSM while the scrim itself contributes to the assembly's fire behavior rather than becoming a hidden combustible path.
Secondary Applications
a) Aluminum Foil Composite
Nove-woven laid scrim is widely applied in aluminium foil industry. It can help manufacture to develop the production efficiency as the roll length can reach 10000m. It also makes the finished product with better apperance.
b) PVC Flooring
PVC Flooring is mainly made of PVC,also other necessary chemical material during manufacture. It is produced by calendering,extrusion progress or other manufacture progress, it is devided into PVC Sheet Floor and PVC Roller Floor. Now all major domestic and foreign manufactures are applying it as the reinforcement layer to avoiding the joint or bulge between pieces, which is caused by the heat expansion and contraction of materials.
c) None-woven category products reinforced
None-woven laid scrim is widely used as reinforced materail on kinds none-woven fabric, such as fiberglass tissue, polyester mat, wipes, also some top ends, such as medical paper. It can makes none-woven products with higher tensile strength,while just add very little unit weight.
d) PVC Tarpaulin
Laid scrim can be used as basic materials to produce truck cover,light awning, banner, sail cloth etc.
