Polyester laid scrims netting laminated for Hot-air balloons for reinforcement solutions

Short Description:

Roll Width: 200 to 2500 mm

Roll Length:: Up to 50 000 m

Yarns Type:: Glass, Polyester, Carbon, Cotton, Flax, Jute, Viscose, Kevlar, Nomex,

Construction:: Square, tri-directional

Patterns:: From 0.8 yarns/cm to 3 yarns/cm

Bonding:: PVOH, PVC, Acrylic, customized

Send email to us Download as PDF

Product Detail

Product Tags

Polyester laid scrims netting laminated Brief Introduction

This product is a specialized Polyester Laid Scrim Netting, a cost-effective reinforcing fabric engineered specifically as a reinforcement solution for hot-air balloons. It is manufactured from continuous polyester filament yarns arranged in an open mesh construction, where the manufacturing process chemically bonds the non-woven yarns together. This grants the scrim unique and enhanced characteristics, making it highly compatible with the materials and lamination processes used in balloon envelope (fabric) manufacturing. Designed to satisfy specific performance requirements, it permits manufacturers to reinforce critical structural areas of hot-air balloons in a very economical and effective manner, contributing to enhanced durability, safety, and flight performance.

Polyester laid scrims netting laminated Characteristics

Comprehensive Functional Properties: The scrim is defined by a robust set of seven core performance characteristics essential for the demanding conditions of flight: dimensional stability, tensile strength, alkali resistance, tear resistance, fire resistance, anti-microbial properties, and water resistance.

High Strength with Light Weight & Standard Specifications: It delivers significant structural reinforcement while adding minimal weight, which is paramount for aviation applications. Available in standard mesh sizes such as 12.5x12.5mm, 10x10mm, 6.25x6.25mm, and 5x5mm, with corresponding optimized weights (e.g., approx. 6.2-6.6 g/m², 8-9 g/m², 12-13.2 g/m², 15.2 g/m²), it offers an excellent strength-to-weight ratio.

Excellent Compatibility & Production Efficiency: Designed to be fully bonded with balloon envelope fabrics (e.g., nylon, polyester). Supplied in very long roll lengths, with each roll reaching up to 10,000 meters, it facilitates continuous, high-efficiency lamination production runs, minimizing downtime and material waste for manufacturers.

Polyester Laid Scrims Data Sheet

Item No.	CF12.5*12.5PH	CF10*10PH	CF6.25*6.25PH	CF5*5PH
Mesh Size	12.5 x 12.5mm	10 x 10mm	6.25 x 6.25mm	5 x 5mm
Weight (g/m2)	6.2-6.6g/m2	8-9g/m2	12-13.2g/m2	15.2-15.2g/m2

The regular supply of non-woven reinforcement and laminated scrim is 12.5x12.5mm,10x10mm,6.25x6.25mm, 5x5mm,12.5x6.25mm etc. The regular supply grams are 6.5g, 8g, 13g, 15.5g, etc.With high strength and light weight, it can be fully bonded with almost any material and each roll length can be 10,000 meters.

Polyester Laid Scrims Application

a) Aluminum Foil Composite

Nove-woven laid scrim is widely applied in aluminium foil industry. It can help manufacture to develop the production efficiency as the roll length can reach 10000m. It also makes the finished product with better apperance.

b) PVC Flooring

PVC Flooring is mainly made of PVC,also other necessary chemical material during manufacture. It is produced by calendering,extrusion progress or other manufacture progress, it is devided into PVC Sheet Floor and PVC Roller Floor. Now all major domestic and foreign manufactures are applying it as the reinforcement layer to avoiding the joint or bulge between pieces, which is caused by the heat expansion and contraction of materials.

c) None-woven category products reinforced

None-woven laid scrim is widely used as reinforced materail on kinds none-woven fabric, such as fiberglass tissue, polyester mat, wipes, also some top ends, such as medical paper. It can makes none-woven products with higher tensile strength,while just add very little unit weight.
