PVC Flooring Layer Connected Fiberglass Scrim netting mesh fabric laminate
PVC Flooring Layer Connected Fiberglass Scrim netting mesh Introduction
This product is a Fiberglass Laid Scrim, a cost-effective, open-mesh reinforcement fabric engineered as the reinforcement layer in PVC flooring (both sheet and roller types) to counteract thermal expansion and contraction of PVC flooring materials, preventing joint separation or bulging between floor pieces. It is manufactured by chemically bonding continuous E-glass filament yarns into a flat-laid open mesh (square or tri-directional), with binder options (PVOH, PVC, Acrylic, or customized) to match PVC calendering, extrusion, and lamination processes. The laid scrim manufacturing process chemically bonds non-woven yarns together, giving the scrim lightweight, high strength, low shrinkage/low elongation, and corrosion resistance. Ruifiber makes these scrims to order for specific usages — designed to satisfy customer requests and be highly compatible with their process and product.
PVC Flooring Layer Connected Fiberglass Scrim netting mesh Characteristics
PVC-Flooring Grade Glass Properties: Dimensional stability, tensile strength, alkali resistance, tear resistance, fire resistance, anti-microbial properties, water resistance — the E-glass scrim survives the heat of calendering/extrusion and the long-term indoor service cycle, while its low elongation restrains differential movement between floor pieces caused by thermal expansion and contraction.
High Strength & Light Weight: The scrim is available in a range of regular mesh sizes and grammages (covering common specifications from fine to coarse grids), delivering high tensile and tear resistance at minimal added weight. It can be fully bonded with almost any material, and each roll length reaches 10,000 meters to support efficient production.
Long Rolls for PVC Calender / Extrusion Lines: Each roll length can be 10,000 meters, which helps manufacturers improve production efficiency and gives finished products better appearance. Fewer splices per shift on high-speed laminating, calendering, and slitting lines feeding PVC sheet/roller flooring mills.
PVC Flooring Layer Connected Fiberglass Scrim netting mesh Data Sheet
|
Item No. |
CF12.5*12.5PH |
CF10*10PH |
CF6.25*6.25PH |
CF5*5PH |
|
Mesh Size |
12.5 x 12.5mm |
10 x 10mm |
6.25 x 6.25mm |
5 x 5mm |
|
Weight (g/m2) |
6.2-6.6g/m2 |
8-9g/m2 |
12-13.2g/m2 |
15.2-15.2g/m2 |
The regular supply of non-woven reinforcement and laminated scrim is 12.5x12.5mm,10x10mm,6.25x6.25mm, 5x5mm,12.5x6.25mm etc. The regular supply grams are 6.5g, 8g, 13g, 15.5g, etc.With high strength and light weight, it can be fully bonded with almost any material and each roll length can be 10,000 meters.
PVC Flooring Layer Connected Fiberglass Scrim netting mesh Application
Primary Use: Reinforcement Layer in PVC Flooring (Sheet & Roller)
The core application of this fiberglass laid scrim is as the reinforcement layer laminated into PVC flooring — both PVC Sheet Floor and PVC Roller Floor — produced by calendering, extrusion, or other manufacture processes. It is laminated into the PVC stack to:
Prevent Joint Separation & Bulge from Thermal Expansion
PVC flooring materials expand and contract with temperature. The scrim's low elongation and multi-directional tensile restrain differential movement between adjacent floor pieces, avoiding joint gaps or surface bulging that compromise floor appearance and function.
Improve Throughput on PVC Lines
10,000 m roll length feeds high-speed calender/extrusion/laminating lines with fewer splice stops — higher yield per shift, more consistent batch appearance on finished flooring rolls/sheets.
Secondary Applications
a) Aluminum Foil Composite
Nove-woven laid scrim is widely applied in aluminium foil industry. It can help manufacture to develop the production efficiency as the roll length can reach 10000m. It also makes the finished product with better apperance.
b) PVC Flooring
PVC Flooring is mainly made of PVC,also other necessary chemical material during manufacture. It is produced by calendering,extrusion progress or other manufacture progress, it is devided into PVC Sheet Floor and PVC Roller Floor. Now all major domestic and foreign manufactures are applying it as the reinforcement layer to avoiding the joint or bulge between pieces, which is caused by the heat expansion and contraction of materials.
c) None-woven category products reinforced
None-woven laid scrim is widely used as reinforced materail on kinds none-woven fabric, such as fiberglass tissue, polyester mat, wipes, also some top ends, such as medical paper. It can makes none-woven products with higher tensile strength,while just add very little unit weight.
d) PVC Tarpaulin
Laid scrim can be used as basic materials to produce truck cover,light awning, banner, sail cloth etc.
